HCR Yamaha YXZ 1000 Duner Long Travel Suspension Kit

HCR Suspension's YXZ Duner Long-Travel Suspension System

Part #: YXZ-02600

*KING shock lead time 10–12 weeks*

Kit Features:

• Usable travel: Over 20" front & over 21" rear
• +4 inches wider per side; adds 8" total track width
• +4 inches of wheelbase added (2" front, 2" rear)
• Minimal weight increase of only 13 lbs while exponentially increasing strength
• Fiber laser-cut construction for precise fit and finish
• CNC’d 4130 heat-treated billet mounting points for increased integrity
• Angled catacomb design for optimal force distribution
• RCV +4 extended axle bars, heat-treated & through-hardened
• Custom King 2.5 HCR Race Series off-road shocks
• Unique trailing-arm inspired design for minimal added weight and increased strength
• High-clearance boxed A-arm design
• Each piece TIG welded for strength and aesthetics
• OEM ball joints reused for smoother travel and less maintenance
• Compatible with stock wheels
• High-clearance arms provide +1.25” ground clearance
• 100% bolt-on installation using factory mounting points
• Larger 1.25” front tube mounts with Delrin bushings for increased strength and durability

Kit Contains:

• (4) Front A-arms
• (4) Rear control arms
• Custom King 2.5 HCR Race Series shocks (HC7349-02 / HC7101-01)
• (4) RCV extended axle bars
• (1) Stock Series shock tower
• (1) Set of tie-rod extensions
• Hardware pack
• YXZ installation guide
