HCR Yamaha YXZ 1000 Dual Sport Long Travel Suspension Kit

Part #: YXZ-02400

*KING shock lead time 10–12 weeks*

HCR Racing proudly introduces the +4 YXZ Complete Long-Travel Suspension System, engineered with the brand’s signature combination of modern design and superior structural integrity. This system delivers enhanced performance, strength, and ground clearance while maintaining precise handling characteristics.

Kit Features:

• Usable travel: over 20" front and over 21" rear
• +4 inches wider per side, for a total of +8" track width
• +4 inches added to the wheelbase (2" front, 2" rear)
• Fiber laser-cut construction ensures precise fitment and finish
• CNC-machined 4130 heat-treated billet mounting points for superior integrity
• Angled catacomb design distributes forces for maximum durability
• RCV +4 extended axle bars, heat-treated and through-hardened
• Custom King 2.5 HCR Race Series off-road shocks
• Unique trailing-arm inspired design enhances strength with minimal weight increase
• High-clearance boxed A-arm design for improved obstacle clearance
• Precision TIG-welded components for strength and visual appeal
• OEM ball joints reused to maintain optimal steering response and reduced maintenance
• Compatible with stock wheel configurations
• High-clearance arms provide an additional 1.25” of ground clearance
• 100% bolt-on installation utilizing factory mounting points
• 1.25” front tube mounts with Delrin bushings for increased strength and longevity

Kit Contains:

• (4) Front A-arms
• (4) Rear control arms
• Custom King 2.5 HCR Race Series shocks (HC7349-02 / HC7101-01)
• (4) RCV extended axle bars
• (1) Stock Series shock tower
• (1) Set of tie-rod extensions
• Hardware pack
• YXZ installation guide
