HCR Duner OEM Replacement Suspension Kit for Can-Am Maverick 64" X3 (2017-2021)

HCR kits are made to order. Quality takes time.

PART# MAV-05200

Features

• 1.5" High clearance A-Arm design allows for added ground clearance under key components.

• Manufactured with HCR Elite Alloy; 30% stronger than 4130 Series Chromoly

• Delrin bushings included for increased strength to mounting points.

• Internal catacomb design allow for increased strength from hollow factory design .

• comparable weight to factory with added structure.

The HCR Racing Duner OEM Replacement Suspension Kit for the Can-Am Maverick X3 is the perfect upgrade to enhance both performance and appearance. The 1.5” high-clearance A-Arm design provides extra ground clearance, while the HCR Elite Alloy that’s 30% stronger than 4130 Chromoly, ensures durability and strength. With Delrin bushings and n internal catacomb design, this kit reinforces key components without adding extra weight.

Kit Includes

• (4) Front A-arms

• (2) Rear trailing arms

• Front A-arm bushings

• Hardware kit

Fitment

• Can-Am Maverick X3 900: 2018

• Can-Am Maverick X3 Turbo: 2017-2020

• Can-Am Maverick X3 Turbo R: 2018-2020

• Can-Am Maverick X3 X DS Turbo R: 2017-2020

• Can-Am Maverick X3 DS Turbo R: 2021

• Can-Am Maverick X3 X DS Turbo RR: 2020-2021

• Can-Am Maverick X3 X MR Turbo: 2018-2021

• Can-Am Maverick X3 X RC Turbo: 2018-2021

• Can-Am Maverick X3 MAX Turbo: 2017-2020

• Can-Am Maverick X3 MAX Turbo R: 2018-2020

• Can-Am Maverick X3 MAX X DS Turbo: 2017-2019

• Can-Am Maverick X3 MAX X DS Turbo R: 2020

• Can-Am Maverick X3 MAX DS Turbo R: 2021

Note

• Will not fit double shear hubs

• Does not come with trailing arm radial bearings (Replace with Can-Am OEM hardware)

• For this kit you will need to reuse or replace with OEM/aftermarket components: Ball joints in the front A-arms, Crush Sleeves and wear plates in the Front A-arms, Trailing arm Radial joints, mounting bolts and hardware otherwise not provided.

• 14" Wheels will not fit

• HCR kits are made to order. Quality takes time
